Gastroenterology endoscopy system: what is included and how to choose
A complete endoscopy system for gastroenterology goes far beyond the endoscope — it includes an image processor, tower, light source, 4K monitor, washer, and accessories. A guide on what you need and how much it costs in Colombia 2026
🔭
GSMED Imaging technical team — endoscopy systems Colombia
GSMED Imaging is an authorized distributor of Olympus, Fujifilm, and Pentax Medical in Colombia. More than 15 years installing complete endoscopy systems in Colombian clinics and hospitals.
The most frequent question when a gastroenterologist opens their office or when a clinic sets up an endoscopy unit is: what exactly do I need? The answer is never just "an endoscope" — a functional endoscopy system has between 8 and 12 components that must be compatible with each other, and the choice of each one affects the diagnostic quality and the long-term operating cost.
1. The components of a complete endoscopy system
🖥️
Image processor (video endoscope)
The brain of the system — it converts the signal from the endoscope camera into an image for the monitor. It determines the resolution (HD, Full HD, 4K), the available image enhancement technologies (NBI, BLI, LCI), and which endoscopes are compatible. Olympus CV-190 (EXERA III), CV-1500 (EVIS X1), Fujifilm EPX-10 (ELUXEO 10).
→ Defines resolution and technologies · Olympus · Fujifilm · Pentax
💡
Light source
Illuminates the inside of the organ through the endoscope's light channel. Two types: xenon (CLV-190, high intensity, requires bulb replacement every 500h) and LED integrated into the processor (Fujifilm ELUXEO — no bulb, lifespan >30,000h). The LED reduces the long-term operating cost.
→ Xenon (CLV-190) vs integrated LED (Fujifilm ELUXEO)
📺
Medical monitor
At least 27" monitor with 4K UHD resolution if the processor is 4K (EVIS X1, ELUXEO 10). Without a 4K monitor, the EVIS X1 displays an HD image. Medical monitors have anti-glare coatings, higher color fidelity, and medical device certification — they cannot be replaced by conventional televisions in clinical use.
→ 27–32" · 4K if processor is 4K · Certified medical monitor
🔭
Endoscopes (gastroscope + colonoscope)
The minimum unit for a general gastroenterology service: a gastroscope (GIF-H190 or GIF-1TH190 in Olympus) for upper endoscopy and a colonoscope (CF-HQ190 or CF-H190 in Olympus) for colonoscopy. Ideally 2 of each to rotate while the other is being washed and sterilized.
→ Minimum: 1 gastroscope + 1 colonoscope · Ideal: 2+2
🧼
Endoscope washer
Mandatory to comply with the reprocessing standard (ANSI/AAMI ST91). Automatic washing with high-level disinfection (HLD) with glutaraldehyde or peracetic acid. Olympus OER-Elite, Medivators DSD-201. Without a certified automatic washer, the service cannot obtain authorization from the Ministry of Health.
→ HLD mandatory · ANSI/AAMI ST91 · Ministry of Health authorization
🛒
Accessories and consumables
Biopsy forceps, sclerotherapy needles, hemostatic clips, polypectomy snares, spray catheters, varicose vein ligation kits, submucosal injectors. Olympus accessories are optimized for their own endoscopes — although there is cross-compatibility with some lower-cost generic brands.
→ Biopsy · Hemostasis · Polypectomy · Procedure kits
2. Complete systems by service level
| Level | Configuration | For whom | Approx. investment Colombia |
|---|---|---|---|
| Basic office | HD processor + xenon light source + 1 gastroscope + 1 colonoscope + washer + 27" monitor | Gastroenterologist starting a private practice · Low volume (5–10 procedures/day) | USD 45,000–70,000 |
| Outpatient unit | Full HD processor + 2 gastroscopes + 2 colonoscopes + double washer + 4K monitor + archiving and documentation system | Outpatient endoscopy center · 15–30 procedures/day | USD 90,000–160,000 |
| 4K + AI hospital unit | EVIS X1 (CV-1500) + ENDO-AID + 2-4 gastroscopes + 2-4 colonoscopes + duodenoscope + automatic washer + complete 4K tower + RIS/HIS system | Level III-IV hospital · CRC screening program · >30 procedures/day | USD 200,000–450,000 |
📋 Frequently asked questions also answered in this article
What is included in a complete endoscopy system?
How much does an endoscopy system cost in Colombia 2026?
Which endoscopes are compatible with the Olympus CV-190 processor?
How many endoscopes do I need for an outpatient endoscopy unit?
Which endoscope washer is mandatory for authorization in Colombia?
Difference between HD and 4K endoscopy system for gastroenterology?
Can I mix Olympus endoscopes with a Fujifilm processor?
No — endoscopes and endoscopy processors are proprietary closed ecosystems. An Olympus endoscope only works with Olympus processors (CV-190 with EXERA III, CV-1500 with EVIS X1). A Fujifilm endoscope only works with Fujifilm processors (EPX-10, VP-7000). Pentax idem with its EPK-i7010 processors. The only exception are some accessories and consumables (biopsy forceps, polypectomy snares) that can be generic brand and be compatible with the working channel of endoscopes of any brand if the channel diameter is the same.
