Complete guide for pregnant women and doctors · ISUOG guidelines · Colombia 2026
Transabdominal obstetric ultrasound: what it evaluates in each trimester, fetal biometry, and how to read the report
Everything you need to know about transabdominal obstetric ultrasound — preparation by trimester, what the sonographer measures, what the report abbreviations mean (DBP, CC, CA, LF, ILA, TN), and when a transvaginal approach is needed
Transabdominal obstetric ultrasound Fetal biometry DBP · CC · CA · LF · ILA Nuchal translucency ISUOG guidelines Colombia 2026
🤰
GSMED Imaging medical-technical team — diagnostic ultrasound specialists
Content based on the ISUOG (International Society of Ultrasound in Obstetrics and Gynecology) Clinical Practice Guidelines for first-trimester ultrasound, the Medicina Fetal Barcelona ultrasound screening protocol, AIUM/SMFM/ACOG Committee Opinion No. 700 on gestational dating, the CERPO protocol (University of Chile), and Colombian clinical references from Iconmedica Bogotá, Clinica Eusalud Bogotá, and Medicina Fetal Colombia.
Published: April 2026 ISUOG Guidelines · AIUM/SMFM/ACOG · Medicina Fetal Barcelona YMYL — Maternal-fetal health
⚠️ Important medical notice: This guide is for informational and educational purposes. The results of your obstetric ultrasound must be interpreted by the obstetrician or maternal-fetal medicine specialist who manages your prenatal care, always in the context of your medical history. This information does not constitute a medical diagnosis. If you have questions about your results, consult your treating physician directly without delay.
You were ordered a transabdominal obstetric ultrasound and have questions: Do you need a full bladder? What will the doctor see? What do all those report abbreviations mean — DBP, CC, CA, LF, ILA, TN? Why do they sometimes say a transvaginal ultrasound is also needed? This guide answers all of that — and also explains why the quality of the ultrasound equipment used for the exam matters as much as the skill of the specialist performing it.
1. What transabdominal obstetric ultrasound is
Transabdominal obstetric ultrasound is the standard imaging exam for pregnancy. It uses high-frequency sound waves — ultrasound — that are sent through the pregnant woman's abdominal wall with a transducer (probe) that slides over the skin with conductive gel. The waves bounce off internal structures — the fetus, placenta, amniotic fluid, uterus — and the returning echoes are converted into real-time images on the ultrasound screen.
"Transabdominal" simply means that the probe is placed on the abdomen — unlike the transvaginal approach, where the transducer is inserted into the vagina. They are two complementary techniques, not mutually exclusive, and each has its precise indications depending on the week of gestation and what needs to be evaluated.
0
Ionizing radiation — completely safe for mother and fetus at all weeks
3
Minimum ultrasounds in a low-risk pregnancy in Colombia (one per trimester)
20–22
Weeks — the optimal time for a morphological ultrasound to detect malformations
88%
Detection rate of central nervous system anomalies in specialized centers (Eurofetus)
2. What it evaluates in each trimester: the 3 fundamental ultrasounds
1
First trimester — Dating, viability, and aneuploidy screening
Weeks 11+0 to 13+6 (optimal window for nuchal translucency)
🔵 Transabdominal (or TV if necessary)
What the sonographer evaluates
- Fetal viability — visible heartbeat
- Number of fetuses — singleton or multiple pregnancy
- Chorionicity and amnionicity in twins
- Crown-rump length (CRL) — for precise dating
- Nuchal translucency (NT) — Down syndrome screening
- Nasal bone — additional aneuploidy marker
- Chorion location (future placenta)
- Basic fetal anatomy: brain, heart, abdomen, limbs
Key first-trimester markers
- Normal NT: < 3 mm between weeks 11+0 and 13+6
- CRL at 12 weeks: ~55–65 mm
- Normal fetal heart rate: 120–160 bpm
- Nasal bone visible in 99% of normal fetuses at 12 weeks
- Evaluation of the ductus venosus (DV) — additional marker
- Tricuspid regurgitation — additional marker
Preparation: Moderately full bladder (drink 2–3 glasses of water 1 hour before and do not urinate). This elevates the uterus and improves the transabdominal ultrasound window. If the uterus is very small or retroverted, a transvaginal approach may be necessary to see clearly.
2
Second trimester — Complete fetal anatomy (morphological ultrasound)
Weeks 20–22 (preferably week 21 according to the Barcelona protocol)
🔵 Standard transabdominal
What the sonographer evaluates
- Complete fetal anatomy — head, face, neck, spine
- Heart — four chambers + outflow tracts
- Abdomen — stomach, kidneys, bladder, abdominal wall
- Limbs — length and shape of long bones
- Fetal sex (if the fetus cooperates)
- Fetal biometry: DBP, CC, CA, LF
- Placental location and insertion
- Amniotic Fluid Index (AFI)
- Cervical length — if there is a risk of preterm birth
What this ultrasound detects
- CNS anomalies — detects ~88% in specialized centers
- Congenital heart disease — detects ~80% in specialized centers
- Renal anomalies — detects ~84%
- Gastroschisis / omphalocele — abdominal wall
- Cleft lip and palate — fetal face
- Placenta previa — low placental insertion
- Early intrauterine growth restriction (IUGR)
Preparation: No special preparation is required. The uterus is already large and provides its own ultrasound window. A full bladder is not needed (unless the cervix is being evaluated). Eat normally on the day of the exam.
3
Third trimester — Fetal growth, well-being, and presentation
Weeks 30–34 (growth ultrasound) + weeks 36–40 (presentation and well-being)
🔵 Transabdominal + Doppler
What the sonographer evaluates
- Updated fetal biometry: DBP, CC, CA, LF
- Estimated fetal weight and percentile
- Fetal presentation — cephalic, breech, or transverse
- AFI — amount of amniotic fluid
- Placental maturity — Grannum grade
- Placental insertion — rule out placenta previa
- Umbilical artery Doppler — utero-placental flow
- Middle cerebral artery Doppler — fetal reserve
What the obstetrician looks for
- IUGR (growth restriction) — weight percentile < 10
- Fetal macrosomia — percentile > 90
- Oligohydramnios (little fluid) or polyhydramnios (much)
- Breech presentation — for external cephalic version or cesarean decision
- Partial or total placenta previa
- Compromised fetal well-being — abnormal Doppler
- Previously undetected progressive fetal pathology
Preparation: No special preparation is required. The baby is large and clearly visible. Vessel Doppler does not require any additional preparation. If the doctor requests a biophysical profile, fasting or a full bladder is also not needed.
3. Transabdominal vs transvaginal: when each is used
🔵 Transabdominal — standard
Approach: Convex transducer over the abdomen with conductive gel
Best from: Week 10–11 onward (when the uterus leaves the pelvis)
Standard for: Second and third trimesters — fetal anatomy, biometry, growth, placenta
Preparation: Moderately full bladder only in the first trimester
Limitations: Low resolution in deep tissues in the first trimester · Difficult with a very retroverted uterus · Maternal obesity limits imaging
🟡 Transvaginal — complementary
Approach: Endocavitary transducer inserted through the vagina
Best in: Early first trimester (weeks 5–10) and when transabdominal is not sufficient
Indications: Confirmation of ectopic pregnancy · NT measurement when transabdominal does not provide the correct angle · Cervical evaluation (cervical length) · Placenta previa (placenta-internal cervical os distance)
Preparation: Empty bladder — facilitates closer access to the uterus
Limitations: Only sees up to ~10 cm depth · Does not evaluate complete fetal anatomy well in the second trimester
When both are ordered in the same visit It is common in first-trimester ultrasound for the obstetrician to start with a transabdominal approach and, if they cannot measure the nuchal translucency well (due to fetal position or uterine position), switch to a transvaginal approach to complete the study. This is not a sign of a problem — it is quality work. In high-complexity centers, the transvaginal approach is offered directly for NT measurement because it provides better images of the fetal neck at 11–14 weeks.
4. Fetal biometry: what they measure and what the abbreviations mean
Fetal biometry is the set of body measurements of the fetus that the sonographer obtains in each exam. They are the report abbreviations that most confuse pregnant women — and that are fundamental for evaluating fetal growth:
DBPBiparietal Diameter
Distance between the two parietal bones of the fetal skull at its widest point. It is measured in the axial plane of the brain at the level of the thalamus. The most precise biometric parameter for estimating gestational age between weeks 14 and 26.
14 weeks: ~25 mm · 20 weeks: ~47 mm · 30 weeks: ~78 mm · Term: ~93 mm
CCHead Circumference
Perimeter of the fetal head, calculated from the DBP and the occipitofrontal diameter (OFD). Allows detection of microcephaly and hydrocephalus. It becomes more precise than the DBP for dating from week 14.
20 weeks: ~175 mm · 28 weeks: ~255 mm · 32 weeks: ~300 mm · 36 weeks: ~330 mm
CAAbdominal Circumference
Perimeter of the fetal abdomen at the level of the liver and umbilical vein. The most sensitive parameter for detecting intrauterine growth restriction (IUGR) and fetal macrosomia. It reflects the nutritional status of the fetus better than any other parameter.
20 weeks: ~148 mm · 28 weeks: ~232 mm · 32 weeks: ~270 mm · 36 weeks: ~315 mm
LFFemur Length
Measurement of the fetal thigh bone — the easiest long bone to measure. Together with the DBP, the LF helps confirm gestational age and detect skeletal dysplasias. Some studies show that the LF is the parameter with the best correlation with gestational age in the second trimester.
14 weeks: ~15 mm · 20 weeks: ~33 mm · 28 weeks: ~53 mm · 36 weeks: ~67 mm
LCR / CRLCrown-Rump Length
The most important measurement of the first trimester. It is the distance from the top of the head to the end of the fetal spine. It is used to precisely calculate gestational age between 9 and 13+6 weeks — margin of error of ± 5–7 days, the most precise of the entire pregnancy.
9 weeks: ~22 mm · 11 weeks: ~44 mm · 12 weeks: ~58 mm · 13+6 weeks: ~84 mm (maximum limit for dating with CRL)
ILAAmniotic Fluid Index
Measurement of the amount of amniotic fluid: the uterus is divided into four quadrants and the maximum vertical pocket of each is measured — the sum is the AFI. Normal values: 8–18 cm. AFI < 5 cm = oligohydramnios. AFI > 24–25 cm = polyhydramnios. Both conditions require additional evaluation.
Normal: 8–18 cm · Lower limit: 5 cm · Upper limit: 24 cm · Alternative: Maximum vertical pocket ≥ 2 cm
Reference fetal biometry table by weeks (50th percentile)
| Week |
CRL (mm) |
DBP (mm) |
CC (mm) |
CA (mm) |
LF (mm) |
Estimated weight (g) |
| 11 weeks |
44 |
— |
— |
— |
— |
~7 g |
| 12 weeks |
58 |
20 |
— |
— |
9 |
~14 g |
| 14 weeks |
84* |
25 |
91 |
87 |
15 |
~43 g |
| 16 weeks |
— |
34 |
122 |
115 |
22 |
~100 g |
| 18 weeks |
— |
40 |
149 |
130 |
28 |
~190 g |
| 20 weeks |
— |
47 |
175 |
148 |
33 |
~300 g |
| 22 weeks |
— |
53 |
197 |
170 |
38 |
~430 g |
| 24 weeks |
— |
60 |
218 |
193 |
43 |
~600 g |
| 28 weeks |
— |
71 |
255 |
232 |
53 |
~1,000 g |
| 32 weeks |
— |
82 |
300 |
270 |
61 |
~1,700 g |
| 36 weeks |
— |
90 |
330 |
315 |
67 |
~2,600 g |
| 40 weeks |
— |
96 |
350 |
355 |
73 |
~3,400 g |
* From a CRL > 84 mm (≥ 14 weeks), the CC is used for dating. Reference values are based on Hadlock et al. and standard obstetric literature. 50th percentile (median). Always interpret in context with the 10–90 percentile range in the report and with maternal clinical findings. Estimated weight margin of error: ±15%.
What it means to be in the "30th percentile" or "70th percentile" Fetal biometric measurements are compared with population reference tables and expressed in percentiles. A fetus in the 50th percentile is the average size for its week. The normal range is from the 10th to the 90th percentile. An estimated weight in the 8th percentile is considered low for gestational age (possible IUGR), and in the 93rd percentile, large for gestational age (possible macrosomia). A percentile outside the normal range is not a diagnosis — it is a warning sign that requires additional evaluation and follow-up.
5. Nuchal translucency and first-trimester screening
Nuchal translucency (NT) is the most important measurement of the first trimester — and the one that causes the most anxiety in pregnant women when the result is not "normal". It is essential to understand what it is and what it is not:
-
What it measures: the amount of fluid that accumulates in the back of the fetus's neck between weeks 11+0 and 13+6. It is measured in millimeters in a strict sagittal plane of the fetus.
-
Reference value: NT < 3 mm is considered normal. Above 3 mm, the risk of chromosomal abnormalities and congenital heart disease increases progressively.
-
It is not a diagnosis: an increased NT does not mean that the baby has Down syndrome — it means that the risk is higher than that of the general population. It is combined with maternal age and biochemical markers (free β-hCG and PAPP-A) to calculate a first-trimester combined risk.
-
Sensitivity of combined screening: first-trimester combined screening (NT + biochemistry + maternal age) detects approximately 85–90% of cases of trisomy 21 with a false-positive rate of 5%.
-
After a high-risk result: definitive diagnosis is offered through chorionic biopsy (10–13 weeks) or amniocentesis (15–18 weeks) — tests with direct chromosomal analysis of fetal material.
NT cannot be measured in any week The window for correctly measuring nuchal translucency is very narrow: between weeks 11+0 and 13+6, with a CRL between 45 and 84 mm. Outside that range, the nuchal fluid changes characteristics and the measurement no longer has the same predictive value. If for any reason your first-trimester ultrasound appointment is after week 14, it is no longer possible to measure NT — and the first-trimester screening remains incomplete.
6. How to read the obstetric ultrasound report
7. Frequent findings and what they mean
📏
Intrauterine growth restriction (IUGR)
The estimated weight or AC is below the 10th percentile for gestational age. It may be due to placental insufficiency, infections, chromosomal abnormalities, or maternal factors. Requires follow-up with umbilical artery and middle cerebral artery Doppler to assess fetal well-being.
→ Doppler follow-up · Does not always require premature delivery
💧
Oligohydramnios
ILA < 5 cm (or maximum vertical pocket < 2 cm). Low amniotic fluid — may indicate fetal kidney problems, premature rupture of membranes, or placental insufficiency. It is one of the findings that generates the most urgency in obstetric follow-up.
→ Requires urgent evaluation of fetal well-being
🌊
Polyhydramnios
ILA > 24–25 cm. Excess amniotic fluid — may be associated with maternal diabetes, fetal swallowing abnormalities (digestive atresias), fetal anemia, or chromosomal abnormalities. In many cases, it is idiopathic (no identifiable cause).
→ Rule out gestational diabetes and fetal abnormalities
🔴
Placenta previa
The lower edge of the placenta covers the ICO (internal cervical os) totally or partially. It can cause bleeding in the third trimester and determine the route of delivery (cesarean section). More precise diagnosis transvaginally to measure the exact distance to the ICO.
→ Mandatory follow-up — many previa migrate in the third trimester
📐
Short uterine cervix
Cervical length < 25 mm before week 24 — risk factor for premature birth. It is measured transvaginally with an empty bladder. It may indicate cervical cerclage or vaginal progesterone depending on the clinical context and obstetric history.
→ Transvaginal measurement with an empty bladder · May be treated
💓
Abnormal umbilical artery Doppler
Resistance to flow in the umbilical artery increases when the placenta malfunctions. In severe cases, absent or reverse diastolic flow appears — a sign of severe fetal compromise. Doppler is the most important fetal monitoring tool in the third trimester of high-risk pregnancies.
→ High-complexity finding — third-level management
8. What obstetric ultrasound CANNOT detect
Obstetric ultrasound is the most valuable prenatal diagnostic tool available — but it has real limitations that your doctor knows and that you must understand so as not to have false expectations:
-
It does not detect chromosomal abnormalities directly: ultrasound sees anatomy — not chromosomes. It can see indirect signs (soft markers) that increase suspicion, but the diagnosis of Down syndrome or other chromosomal abnormalities requires chromosomal analysis: chorionic biopsy, amniocentesis, or fetal DNA in maternal blood (NIPT).
-
It does not detect metabolic or biochemical defects: storage diseases, inborn errors of metabolism, enzyme deficiencies — they do not have detectable ultrasound expression.
-
The detection rate of malformations is not 100%: even in specialized centers, the sensitivity for heart disease is ~80% and for CNS abnormalities ~88%. Some malformations have minimal or late ultrasound expression.
-
It depends on the operator, the equipment, and the conditions of the exam: the quality of the ultrasound machine, the transducer frequency, the specialist's experience, the pregnant woman's body mass index, and the fetus's position directly affect the image quality and therefore the diagnostic capacity.
-
A normal ultrasound is not an absolute guarantee: as established by the Barcelona Fetal Medicine protocol, the standard conclusion specifies that "anomalies that do not have ultrasound expression cannot be ruled out" — it is an honest and necessary limitation of the method.
Are you looking for high-resolution obstetric ultrasound machines for your center?
At GSMED, we have ultrasound machines for obstetrics with high-definition convex transducers, color Doppler, and 4D capability available in Colombia, with local technical support and specialized advice.
View obstetric ultrasound machines →
9. Frequently asked questions about transabdominal obstetric ultrasound
Do I need a full bladder for transabdominal obstetric ultrasound?
It depends on the trimester. In the first trimester (especially before week 12), it is recommended to have a moderately full bladder — 2 to 3 glasses of water one hour before the exam without urinating. A full bladder displaces the uterus upward and improves the ultrasound window when the uterus is still inside the pelvis. In the second and third trimesters, you do not need special preparation — the uterus is already large enough to provide its own window. If your medical order does not specify, ask at the center where they will perform it before going.
How often should ultrasounds be done during pregnancy?
In Colombia, standard prenatal care for a low-risk pregnancy includes at least three ultrasounds: one in each trimester (11–14 weeks, 20–22 weeks, 30–34 weeks). In high-risk pregnancies — gestational diabetes, hypertension, IUGR, twins, history of premature birth — the number of ultrasounds increases at the obstetrician's discretion, who may indicate follow-ups every 2–4 weeks or even weekly in the most complex cases. The pregnant woman's desire to see the baby is not a medical indication for additional ultrasounds — although many centers in Colombia offer 3D/4D ultrasounds for prenatal bonding purposes outside of obstetric care.
Can obstetric ultrasound harm the baby?
No. The safety of diagnostic ultrasound in pregnancy is well established by decades of clinical use and prospective studies. ISUOG guidelines specify that B-mode (conventional imaging) and M-mode (for fetal heart rate) are safe at all stages of pregnancy. First-trimester pulsed Doppler is associated with higher energy production — ISUOG guidelines recommend using it only when clinically indicated, not routinely in the first trimester. In the second and third trimesters, Doppler is safe and commonly used.
What does "no heartbeat observed" mean?
If the ultrasound machine does not detect a fetal heartbeat in a pregnant woman with a confirmed pregnancy, it may mean: (1) that the pregnancy is at a very early stage (less than 6 weeks) and the embryo does not yet have a visible heartbeat — in that case, she will be seen again in 1–2 weeks; (2) that there is an embryonic abortion (no embryonic development — "anembryonic egg") or a pregnancy loss. The obstetrician will evaluate the clinical context, β-hCG levels, and may order a transvaginal ultrasound to confirm. This result must always be communicated and evaluated directly by the doctor who manages the prenatal care.
How much does a transabdominal obstetric ultrasound cost in Colombia in 2026?
In the Colombian health system (EPS/IPS), obstetric ultrasound is included in the Health Benefits Plan (PBS) for prenatal care ultrasounds — at no additional cost to the patient when requested by the treating doctor. In the private sector, prices vary by city and center level: a basic obstetric ultrasound in Colombia ranges from $80,000 to $200,000 COP. Second-trimester morphological ultrasound with complete fetal anatomy can cost between $150,000 and $350,000 COP. 3D/4D ultrasound (without additional medical value compared to 2D for obstetric care) has variable prices from $100,000 to $500,000 COP depending on the package offered.
